| Connectivity |
Specifications |
| Frequency Band |
US Version:
GSM：850MHz/900MHz
WCDMA：B1/B2/B4/B5(B19)/B7/B12(B17)/B13/B28
European Version:
GSM：850MHz/900MHz/1800MHz/1900MHz
WCDMA：B1/B2/B5/B8
TD-SCDMA：B34/B39
CDMA2000: BC0
TDD-LTE：B38/B39/B40/B41
FDD-LTE：B1/B3/B7/B8/B20/B28A&B |
| WiFi |
FPC WiFi/ IEEE802.11a/IEEE802.11b/IEEE802.11g/IEEE802.11n(1T1R) |
| Bluetooth |
BT Coexistence/Version BT 4.0 with BLE & BT2.1+EDR(Enhanced Data Rate) |
| NFC |
Support |
| GPS |
GPS/GLONASS/AGPS |
| Hardware |
Specifications |
| CPU |
MTK6739 quad-core |
| Memory |
2+16GB |
| Display |
5.5" Capacitive Touch Panel + Touch Keypad 128*720dpi |
| Camera |
Front Camera 2MP, External USB Camera DB9 interface support USB Camera |
| Speaker |
φ50mm 4Ω 5W, External Speak DB9 Interface Dual MIC, DMR POC Use Microphone Independently |
| Dimensions(H*W*D) |
190*93*66mm/498g |
| Battery |
Power Supply 12V Input Voltage |
| USB Port |
Support SW DL, USB Camera, 3.3V Uart, SPEAKER OUT |
| Interface |
Peripheral Interface/ External Hand MIC Interface/ External Antenna Interface1.2 |
| Sensors |
G Sensor &Gyroscope/ Compass |
| Software |
Specifications |
| Operating Systems |
Android 8.1 |
| Physical |
Specifications |
| Working Temperature |
-20~70℃ |
| Storage Temperature |
-30~80℃ |
| Protection Rating |
IP54 |
| DMR(optional) |
Support DMR UHF 400~470 VHF136~176 |
